16 Ton FARGER & JOOSTEN MULTIPOWER Air/Oil Press
Serial Number: 2720
SPECIFICATIONS:
This is a Multipling type Air over Oil Press
See: https://farger-joosten.de
NOTE: Will Sell Either Power Unit on the Mounting Plate with a
Four Post Guided Ram or Everything at the Same Price. We will
Remove, Properly Pack and Protect the Power Unit for Shipping
Housing Style Press With a 4 Post Guided Ram
Built for Side to Side Feed
Tonnage: 16 Ton
Stroke: 7.9" (adjustable), the last .79" Power Stroke
Daylight Opening: 13"
Bed & Ram: 14" x 14" x 2" Thick
Force in Approach Stroke: 1,260 lbs
Force in Retract Stroke: 1,260 lbs
Force in Power Stroke: 16 ton (US)
Pass Line, Floor to Top of Bed: 40"
NOTE: Power Units are Fully Supported through Schmidt Presses,
Cranberry, PA.
OVERALL DIMENSIONS: 34" LR x 50" FB x 125" High
